JBC DI 1 Tool Control Unit
This DI manages 1 tool for soldering or desoldering and is fully compatible with 10 different JBC tools. Check below the complete list of compatible tools.The DI works with the JBC exclusive Heating System and the intelligent sleep & hibernation features to extend a tip´s life up to 5 times longer.Using the menu you can personalize over 20 parameters to help manage the soldering process.The USB connector allows to update software, create graphs and manage parameters from a PC.For a basic working system, you need at least 1 stand, 1 tool and 1 cartridge.
Qualities and Characteristics
- Personalize over 20 parameters to help manage the soldering process.
- JBC exclusive Heating System
- Sleep & Hibernation modes help to extend life of tips.
- USB connector allows to update software, create graphs and manage parameters from a PC
- ESD Safe
Product Contains
- 1 DI-2D 1 Tool Control Unit
Selectable Parameters
| Selectable Temperature | 90 to 450 ºC / 190 to 840 ºF |
Special Features
| Sleep and Hibernation Mode | These modes lower soldering tip temperature when the tool rests in the stand in order to avoid oxidation and extending tip life. |
| Max. and min. temperature | Limit the temperature range in which the operator is allowed to work. |
| Temperature Levels | Instant selection of up to 3 editable temperature settings for solder joints with different heat requirement. |
| PIN protection | Keep station parameters protected against unauthorized access. |
ESD/EOS
| ESD | Safe |
Power Supply
| Peak Power | 130 W - 23.5V |
| Ambient operating temp. | 10 to 40 ºC / 50 to 104 ºF |
Connectivity
| USB-B | Front:Firmware upgrade / Software PC / Traceability |
Write Your Own Review
£482.00
(£578.40
inc VAT)
JBC DI (A.K.A DIU) 1 Tool Control Unit
