JBC DME 4 Tool Control Unit
The DME manages up to 4 tools simultaneously and is fully compatible with 10 different JBC tools. Check below the complete list of compatible tools.It works with the JBC exclusive Heating System and the intelligent sleep & hibernation modes.It features all the Excellence range benefits such as station customization, full control over the soldering process and remote work management.Includes the Dynamic Soldering Profiles functionality, designed to avoid thermal shock when soldering Ceramic Chip components like MLCC.The easy-to-use menu helps you monitor the work in real time: graphics, partial counters or simultaneous control of ports.The DME also provides you with extra applications that support your work: USB microscope, file storage, unit converter, video, etc.For a basic working system, you need 1 stand, 1 tool and 1 cartridge.
Qualities and Characteristics
- Dynamic Soldering Profiles
- Sleep and Hibernation mode
- Max. and min. temperature
- Temperatue levels
- Soldering graphics
- PIN protection
- 10 user interface languages
Product Contains
- 1 DME 4 Tools Control Unit
Selectable Parameters
| Selectable Temperature | 90 to 450 ºC / 190 to 840 ºF |
| Dynamic Soldering Profiles | Designed to avoid thermal shock.Up to 25 fully configurable soldering profiles can be stored |
Special Features
| Sleep and Hibernation Mode | These modes lower soldering tip temperature when the tool rests in the stand in order to avoid oxidation and extending tip life. |
| Max. and min. temperature | Limit the temperature range in which the operator is allowed to work. |
| Temperature Levels | Instant selection of up to 3 editable temperature settings for solder joints with different heat requirement. |
| Soldering Graphics | Real time visualization of tip temperature and power delivered to the solder joint during soldering process. |
| PIN protection | Keep station parameters protected against unauthorized access. |
| 10 User Interface Languages | English, German, Spanish, French, Italian, Portuguese, Russian, Japanese, Korean, Chinese. |
ESD/EOS
| ESD | Safe |
Power Supply
| Peak Power | 160 W - 23.5V |
| Ambient operating temp. | 10 to 40 ºC / 50 to 104 ºF |
Connectivity
| USB-B | Rear:Software PC / Traceability |
| USB-A | Front:Firmware update / Soldering Graphics management / Dino-Lite USB microscope connection. Compatible models: AM2011 and AM2111 |
| Robot | RS-232 remote control or Smart Fume Extractor connection |
| LAN | Remote control / Traceability |
| PS | Interconnection of up to 5 PSE control units to manage up to 24 tools simultaneously. |
