JBC JNASE-2A High Precision Hot Air Stations
The hot air station for the smallest components.It is perfect for reworking SMD components on surfaces with minimal separation.It allows easy reworking of ultra-miniature SMD components (01005) under the magnifying glass.It enables flow regulation of temperatures and air at very low levels in order to avoid the expulsion/movement of adjoining components.JBC offers three cartridge sizes with outlet diameters of 0.8, 1 and 1.2 mm, which are easily interchangeable.The station includes a Pick & Place activated by pedal to position and remove components with high precision.
Qualities and Characteristics
- Enables flow regulation of temperatures and air at very low levels in order to avoid the expulsion/movement of adjoining components.
- Includes a Pick & Place activated by pedal to position and remove components with high precision.
- ESD Safe
Product Contains
- 1 JNASE-2A 230V Hot Air Station
- 1 SCH-A Cartridge Holder
- 1 J115-010 RESISTANCE.JNASE Ø1,0MM
- 1 0861660 Bent Needles for T-260A
- 1 P-405 Pedal
- 1 T260-A Pick & Place
- 1 PH218 Thermocouple Type K
- 1 PH217 Kapton tape
Technical Attributes
| Nominal Power | 70 W |
| Vacuum | 53% / 397 mmHg / 15.6 inHg |
Practical Attributes
| Communication Connectors | USB-A / USB-B,RJ12 for RS232,Pedal / Stand |
Selectable Parameters
| Temperature Selection | 150 - 450 °C / 300 - 840 °F (Room temp.) |
| Air Flow Regulation | 0.15 - 2.5 SLPM |
Special Features
| Cool Mode | Used to blow air at room temperature |
ESD/EOS
| ESD | Safe |
Power Supply
| Ambient operating temp. | 10 - 50 ºC / 50 - 120 ºF |
Write Your Own Review
£1,725.00
(£2,070.00
inc VAT)
JBC JNASE (A.K.A JNA) High Precision Hot Air Stations
